LED Downlight Spotlight 20W 1,800Lm 6000ºK Rectangular Tilting 40,000H [HO-DRECTBAS-20W-CW]

LED Downlight Spotlight 20W 1,800Lm 6000ºK Rectangular Tilting 40,000H [HO-DRECTBAS-20W-CW]

See questions and answers

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce / Epistar Led
  • SkuHO-DRECTBAS-20W-CW
  • A 2021
Eprel file
Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 60 º Opening
32,48€
32,48€ Infinity%
Tax included. The Shipping expenses They are calculated on the payment screen.

Available

Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 60 º Opening
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
(HO-DRECTBAS-20W-CW_padreImg_ho_drectbas_20w_cw_0.jpeg)
Cool White
Available
Free shipping
32,48€
32,48€ Infinity%

Accessories

  • (GH-90963601_padreImg_gh_90963601_0.jpeg) (GH-90963601_padreImg_gh_90963601_1.jpeg)

    Switch Panasonic Karre 10A 250V/Metal Frame With Claws/Key White

    PANASONIC

    Switch Panasonic Karre 10A 250V/Metal Frame With Claws/Key White

    4,37€
    4,37€ Infinity%
  • (SB-BS031B_padreImg_sb_bs031b_0.jpeg) (SB-BS031B_padreImg_sb_bs031b_1.jpeg)

    Motion Sensor Recessed 160º ►600W/200W

    GreenIce

    Motion Sensor Recessed 160º ►600W/200W

    4,36€
    4,36€ Infinity%

Technical file

Product code
HO-DRECTBAS-20W-CW
Luminous efficacy (LM/W)
90
Light temperature
Cold white
Kelvin º
6000
Power (W)
20.0
Luminosity (LM)
1800
Measures (mm)
229x144x90
Roof cut (mm)
221x104
High
90.0
Long
229.0
Broad
144.0
Number and type of LEDs
Epistar Led
CRI
80
UGR
◄19
Power factor (PF)
0.98
Construction
Aluminum/PC
Opening Angle (º)
60
Facility
IP20
Strain
85-265VAC
Estimated life (H)
40000
Dimable
No
Equivalence (W)
135
Isolation class
II
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Diffuser
Transparent
Energy consumption (kWh/1000h)
20.0
Weight (gr)
1350
Flicker
0.92
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
25
Minimum cri range
93
Maximum cri range
7
Chromaticity x
0.322
Chromaticity y
0.349
Driver output
DC24-36V
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Characteristics

Product code
HO-DRECTBAS-20W-CW
Luminous efficacy (LM/W)
90
Light temperature
Cold white
Kelvin º
6000
Power (W)
20.0
Luminosity (LM)
1800
Measures (mm)
229x144x90
Roof cut (mm)
221x104
High
90.0
Long
229.0
Broad
144.0
Number and type of LEDs
Epistar Led
CRI
80
UGR
◄19
Power factor (PF)
0.98
Construction
Aluminum/PC
Opening Angle (º)
60
Facility
IP20
Strain
85-265VAC
Estimated life (H)
40000
Dimable
No
Equivalence (W)
135
Isolation class
II
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Diffuser
Transparent
Energy consumption (kWh/1000h)
20.0
Weight (gr)
1350
Flicker
0.92
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
25
Minimum cri range
93
Maximum cri range
7
Chromaticity x
0.322
Chromaticity y
0.349
Driver output
DC24-36V
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Description

The LED Downlight has a rectangular design and an elegant finish. It is the perfect lighting element for commercial spaces or spaces that are active for many hours a day.

These LED spotlights from the Retail family are the ideal solution if you are looking for recessed projectors with which to direct the light as they tilt up to 60º from their original position. With its attractive design, its excellent features and minimal energy consumption, it is the perfect LED lighting to enhance spaces, decorative elements or products. Thus, they contribute to creating different environments.

They are widely used in shops, warehouses, restaurants, supermarkets, exhibition halls, museums, etc.
