Module 1W 90Lm 6000ºK 1 LED PRO 5630 Injected IP67 50,000H [RA-BL-2323W01-LENS-CW]

Module 1W 90Lm 6000ºK 1 LED PRO 5630 Injected IP67 50,000H [RA-BL-2323W01-LENS-CW]

For additional amounts the delivery period is 30 days As of the order date
  • Brand:GreenIce / Samsung Led
  • SkuRA-BL-2323W01-LENSCW
  • A 2021
Eprel file
Warranty
  • Warranty 3 years
  • 120 º Opening
Documents
1,22€
1,22€ Infinity%
Tax included. The Shipping expenses They are calculated on the payment screen.

There are few

Warranty
  • Warranty 3 years
  • 120 º Opening
Documents
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
(RA-BL-2323W01-LENSCW_padreImg_ra_bl_2323w01_lenscw_0.jpeg)
Cool White
There are few
Free shipping
1,22€
1,22€ Infinity%

Accessories

  • (NK-TR-12VDC-30E-IP_padreImg_nk_tr_12vdc_30e_ip_0.jpeg) (NK-TR-12VDC-30E-IP_padreImg_nk_tr_12vdc_30e_ip_1.jpeg)

    Transformer LED 30W 230VAC/12VDC IP67 IP67

    GreenIce

    Transformer LED 30W 230VAC/12VDC IP67 IP67

    6,97€
    6,97€ Infinity%
  • (KD-TRIP2560W5A_padreImg_kd_trip2560w5a_0.jpeg)

    LED transformer 12VDC 60W/5A IP20 [KD-TRIP2560W5A]

    GreenIce

    LED transformer 12VDC 60W/5A IP20 [KD-TRIP2560W5A]

    5,97€
    5,97€ Infinity%

Technical file

Product code
RA-BL-2323W01-LENS-CW
Luminous efficacy (LM/W)
90
Light temperature
Cold White
Kelvin º
6000
Power (W)
1.0
Luminosity (LM)
90
Measures (mm)
32x18
High
32.0
Broad
18.0
Number and type of LEDs
Samsung Led
CRI
80
Power factor (PF)
0.8
Construction
PVC/ ABS
Opening Angle (º)
120
Facility
IP67
Strain
12VDC
Estimated life (H)
50000
Dimable
No
Equivalence (W)
9
Isolation class
III
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-40 +60
Lighting cycles
100000
Diffuser
Milky
Energy consumption (kWh/1000h)
1.0
Weight (gr)
90
Half -year useful life (at 3 h/day)
45.66
Half -Year Useful Life (5 h/day)
27.39
Half -year useful life (at 8 h/day)
17.12
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
22
Minimum cri range
85
Maximum cri range
13
Chromaticity x
0.304
Chromaticity y
0.312
Additional information
Transformer required in the "Accessories" tab
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000-3-2:2006; EN 61000-3-3:2008; EPA 3050B:1996; EN 1122B:2001; EPA 3052:1996; EPA 3060A:1996; EPA 7196A:1992; EPA 3540C:1996; EPA 8270D:2007; IEC 62321:2008

Characteristics

Product code
RA-BL-2323W01-LENS-CW
Luminous efficacy (LM/W)
90
Light temperature
Cold White
Kelvin º
6000
Power (W)
1.0
Luminosity (LM)
90
Measures (mm)
32x18
High
32.0
Broad
18.0
Number and type of LEDs
Samsung Led
CRI
80
Power factor (PF)
0.8
Construction
PVC/ ABS
Opening Angle (º)
120
Facility
IP67
Strain
12VDC
Estimated life (H)
50000
Dimable
No
Equivalence (W)
9
Isolation class
III
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-40 +60
Lighting cycles
100000
Diffuser
Milky
Energy consumption (kWh/1000h)
1.0
Weight (gr)
90
Half -year useful life (at 3 h/day)
45.66
Half -Year Useful Life (5 h/day)
27.39
Half -year useful life (at 8 h/day)
17.12
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
22
Minimum cri range
85
Maximum cri range
13
Chromaticity x
0.304
Chromaticity y
0.312
Additional information
Transformer required in the "Accessories" tab
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000-3-2:2006; EN 61000-3-3:2008; EPA 3050B:1996; EN 1122B:2001; EPA 3052:1996; EPA 3060A:1996; EPA 7196A:1992; EPA 3540C:1996; EPA 8270D:2007; IEC 62321:2008

Description

The SAMSUNG LED module offers solutions for arrays with versatile LED modules in indoor environments for industrial, commercial and residential use. It can be installed directly at 12 volts in direct current.

It has a high efficacy (90 Lm/W) consuming 1W through 1 SMD5630-type LED and managing to provide a luminous flux of 90Lm uniformly distributed through a transparent optic from which a color rendering index of 80 is obtained. Its consumption represents a value of 1kWh/1000h, reducing the amount of energy billed and the emissions of polluting gases into the atmosphere.The module has a degree of protection IP67 (valid for dust and humidity outdoors), it is sufficiently robust enough to meet the required mechanical requirements. It includes a 3M tape on the back to be fixed, additionally it has a hole in case it needs to be fixed with a screw. It has a white finish.

This module is available in cool white (6000 °K), natural white (4000 °K) and warm white (3000 °K). The indicated color temperature may suffer fluctuations corresponding to a tolerance of 7%.
