Proyector de Estadio Modular 750W-160Lm/W Meanwell LED Philips 0-10V 90º 6000ºK IP65 100.000H

Proyector de Estadio Modular 750W-160Lm/W Meanwell LED Philips 0-10V 90º 6000ºK IP65 100.000H

See questions and answers

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce / MEANWELL
  • Sku1916-ST-750W-90-CW
  • AAA 2021
Warranty
  • Warranty 10 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 90 º Opening
603,66€
603,66€ Infinity%
Tax included. The Shipping expenses They are calculated on the payment screen.

Available

Warranty
  • Warranty 10 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 90 º Opening
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
(1916-ST-750W-90-CW_padreImg_1916_st_750w_90_cw_0.jpeg)
Blanco Frío
Available
Free shipping
603,66€
603,66€ Infinity%

Technical file

Product code
1916-ST-750W-90-CW
Light temperature
CW
Kelvin º
6000
Power (W)
750.0
Luminosity (LM)
120000
Luminous efficacy (LM/W)
160
LED efficacy
176
Type of LEDs
Philips LED
Number of LEDs
864
Measures (mm)
495x603x108
High
603.0
Long
495.0
Broad
108.0
CRI
80
Power factor (PF)
0.99
Construction
Alu/PC
Opening Angle (º)
90
Facility
IP65
IK Protection Index
IK10
Strain
100-277VAC
Estimated life (H)
100000
Dimable
0-10V
Isolation class
I
Work frequency (Hz)
50/60
Start time (s)
0.1
Certificates
CE/ROHS/ENEC/ISO9001
Temperature range (ºC)
-20+60
Lighting cycles
100000
Energy consumption (kWh/1000h)
750.0
Weight (gr)
18000
Half -year useful life (at 3 h/day)
91.32
Half -Year Useful Life (5 h/day)
54.79
Half -year useful life (at 8 h/day)
34.24
Single CCT
6000
INDEX R9
10
Minimum cri range
76
Maximum cri range
90
Driver
Meanwell

Characteristics

Product code
1916-ST-750W-90-CW
Light temperature
CW
Kelvin º
6000
Power (W)
750.0
Luminosity (LM)
120000
Luminous efficacy (LM/W)
160
LED efficacy
176
Type of LEDs
Philips LED
Number of LEDs
864
Measures (mm)
495x603x108
High
603.0
Long
495.0
Broad
108.0
CRI
80
Power factor (PF)
0.99
Construction
Alu/PC
Opening Angle (º)
90
Facility
IP65
IK Protection Index
IK10
Strain
100-277VAC
Estimated life (H)
100000
Dimable
0-10V
Isolation class
I
Work frequency (Hz)
50/60
Start time (s)
0.1
Certificates
CE/ROHS/ENEC/ISO9001
Temperature range (ºC)
-20+60
Lighting cycles
100000
Energy consumption (kWh/1000h)
750.0
Weight (gr)
18000
Half -year useful life (at 3 h/day)
91.32
Half -Year Useful Life (5 h/day)
54.79
Half -year useful life (at 8 h/day)
34.24
Single CCT
6000
INDEX R9
10
Minimum cri range
76
Maximum cri range
90
Driver
Meanwell

Description

El Foco Proyector LED Modular Driver Meanwell 0-10V destaca por su diseño moderno e innovador. Diseñado para el alumbrado deportivo a los más altos niveles de competición y exigencia deportiva.

Equipado con un driver Meanwell regulable 0-10V que permite ajustar la intensidad lumínica según las necesidades específicas del entorno.

Ofrece un gran flujo Lumínico, una gran eficiencia óptica, una sencilla instalación y mantenimiento, unidos a una gran fiabilidad y flexibilidad.

Cuenta con una vida útil elevada, en torno a 100.000 horas, además proporciona un aumento considerable del ahorro energético gracias a los componentes de alta calidad que lo integran.

Su potencia, unido a su gran luminosidad del Foco Proyector LED Modular Driver Meanwell 0-10V, lo convierten en una opción perfecta para zonas deportivas de interior y exterior, gracias a su alto grado de protección IP65. Es la mejor opción para el alumbrado de muelles, estadios, o recintos a los que se quiera dotar de una iluminación especial.

Su diseño modular permite adaptarse a proyectos complejos y reemplazar piezas específicas, prolongando su vida útil.
