LED ceiling light 18W 1800Lm 6000ºK Circular 12VDC 40,000H [JL-JM18WR-12V-CW]

LED ceiling light 18W 1800Lm 6000ºK Circular 12VDC 40,000H [JL-JM18WR-12V-CW]

See questions and answers

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce / Epistar Led
  • SkuJL-JM18WR-12V-CW
  • AA 2021
Eprel file
Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening
16,01€
16,01€ Infinity%
Tax included. The Shipping expenses They are calculated on the payment screen.

Stock available

Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
(JL-JM18WR-12V-CW_padreImg_jl_jm18wr_12v_cw_0.jpeg)
Cool White
Stock available
Free shipping
16,01€
16,01€ Infinity%

Technical file

Product code
JL-JM18WR-12V-CW
Light temperature
Cold white
Kelvin º
6000
Power (W)
18.0
Luminosity (LM)
1800
Luminous efficacy (LM/W)
100
LED efficacy
110
Type of LEDs
Epistar Led
Number of LEDs
90
Measures (mm)
Ø216x36
Roof cut (mm)
Ø205
High
36.0
Diameter
216
CRI
80
Diffuser
Milky
Power factor (PF)
0.8
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP20
Strain
12VDC
Driver output
DC12-21V
Estimated life (H)
40000
Dimable
No
Equivalence (W)
120
Isolation class
III
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Energy consumption (kWh/1000h)
18.0
Weight (gr)
465
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
6
Minimum cri range
85
Maximum cri range
21
Chromaticity x
0.319
Chromaticity y
0.338
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Characteristics

Product code
JL-JM18WR-12V-CW
Light temperature
Cold white
Kelvin º
6000
Power (W)
18.0
Luminosity (LM)
1800
Luminous efficacy (LM/W)
100
LED efficacy
110
Type of LEDs
Epistar Led
Number of LEDs
90
Measures (mm)
Ø216x36
Roof cut (mm)
Ø205
High
36.0
Diameter
216
CRI
80
Diffuser
Milky
Power factor (PF)
0.8
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP20
Strain
12VDC
Driver output
DC12-21V
Estimated life (H)
40000
Dimable
No
Equivalence (W)
120
Isolation class
III
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Energy consumption (kWh/1000h)
18.0
Weight (gr)
465
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
6
Minimum cri range
85
Maximum cri range
21
Chromaticity x
0.319
Chromaticity y
0.338
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Description

LED ceiling light 18W 1,190Lm 6000ºK Circular 12VDC 40,000H [JL-JM18WR-12V-CW]
