LED High Bay 200W 36,000Lm 6000ºK Osram IP65 Driver Lifud Flicker Free Dimmable 0-10V 100,000H [1916-HVUFO200W-H-CW]

LED High Bay 200W 36,000Lm 6000ºK Osram IP65 Driver Lifud Flicker Free Dimmable 0-10V 100,000H [1916-HVUFO200W-H-CW]

See questions and answers

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce / Lifud Driver
  • Sku1916-HVUFO200W-H-CW
  • AAA 2021
Eprel file
Warranty
  • Warranty 7 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 120 º Opening
45,72€
45,72€ Infinity%
Tax included. The Shipping expenses They are calculated on the payment screen.

Stock available

Warranty
  • Warranty 7 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 120 º Opening
¿Eres Cliente Profesional?

Hemos publicado una nueva web solo para Profesionales.

ir a Área Profesional
VENTAJAS DE COMPRAR EN GREENICE
  • Precio Mínimo Garantizado
  • Devoluciones Gratis hasta en 60 días
  • Envío Gratis desde 21,95€
  • Hasta 10 años de Garantía
(1916-HVUFO200W-H-CW_padreImg_1916_hvufo200w_h_cw_0.jpeg)
Cool White
Stock available
Free shipping
45,72€
45,72€ Infinity%

Technical file

Product code
1916-HVUFO200W-H-CW
Light temperature
Cold white
Kelvin º
6000
Power (W)
200.0
Luminosity (LM)
36000
Luminous efficacy (LM/W)
180
LED efficacy
198
Type of LEDs
Osram LED
Measures (mm)
73,5xØ360
High
74.0
Diameter
360
CRI
80
Diffuser
Transparent
Power factor (PF)
0.99
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP65
IK Protection Index
IK08
Strain
120-277VAC
Estimated life (H)
100000
Dimable
Yes
Equivalence (W)
1070
Isolation class
I
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
D
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-40 +60
Lighting cycles
100000
Energy consumption (kWh/1000h)
200.0
Weight (gr)
2750
Flicker
0.45
Half -year useful life (at 3 h/day)
91.32
Half -Year Useful Life (5 h/day)
54.79
Half -year useful life (at 8 h/day)
34.24
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
8
Minimum cri range
90
Maximum cri range
19
Chromaticity x
0.354
Chromaticity y
0.364
Driver
Lifud
Applicable standards
EN 55015:2013; EN 61547:2009; EN 61000-3-2:2014; EN 61000-3-3:2013

Características

Product code
1916-HVUFO200W-H-CW
Light temperature
Cold white
Kelvin º
6000
Power (W)
200.0
Luminosity (LM)
36000
Luminous efficacy (LM/W)
180
LED efficacy
198
Type of LEDs
Osram LED
Measures (mm)
73,5xØ360
High
74.0
Diameter
360
CRI
80
Diffuser
Transparent
Power factor (PF)
0.99
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP65
IK Protection Index
IK08
Strain
120-277VAC
Estimated life (H)
100000
Dimable
Yes
Equivalence (W)
1070
Isolation class
I
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
D
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-40 +60
Lighting cycles
100000
Energy consumption (kWh/1000h)
200.0
Weight (gr)
2750
Flicker
0.45
Half -year useful life (at 3 h/day)
91.32
Half -Year Useful Life (5 h/day)
54.79
Half -year useful life (at 8 h/day)
34.24
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
8
Minimum cri range
90
Maximum cri range
19
Chromaticity x
0.354
Chromaticity y
0.364
Driver
Lifud
Applicable standards
EN 55015:2013; EN 61547:2009; EN 61000-3-2:2014; EN 61000-3-3:2013

Descripción

LED High Bay 200W 36,000Lm 6000ºK Osram IP65 Driver Lifud Flicker Free Dimmable 0-10V 100,000H [1916-HVUFO200W-H-CW]

Documentos

Installation_manual
Spanish_technical_data
Eu_certificates
Technical_drawings
