LED Panel 28W 2800Lm 6000ºK 60X30Cm 40,000H Driver Lifud [HO-PBD-3060-LI-CW]

LED Panel 28W 2800Lm 6000ºK 60X30Cm 40,000H Driver Lifud [HO-PBD-3060-LI-CW]

See questions and answers

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce + Lifud Driver
  • Sku:HO-PBD-3060-LI-CW
Eprel file
Warranty
  • Warranty 5 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 120 º Opening
  • Certificado ENEC
11,39€
11,39€ Infinity%
Tax included. The Shipping expenses They are calculated on the payment screen.

Stock available

Warranty
  • Warranty 5 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 120 º Opening
  • Certificado ENEC
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
(HO-PBD-3060-LI-CW_padreImg_ho_pbd_3060_li_cw_0.jpeg)
Cool White
Stock available
Free shipping
11,39€
11,39€ Infinity%

Accessories

Technical file

Product code
HO-PBD-3060-LI-CW
Light temperature
Cold White
Kelvin º
6000
Power (W)
28.0
Luminosity (LM)
2800
Luminous efficacy (LM/W)
100
LED efficacy
110
Type of LEDs
Samsung Led
Number of LEDs
24
Measures (mm)
295x595x35
High
35.0
Long
595.0
Broad
295.0
CRI
80
UGR
◄19
Diffuser
Microprismatic
Power factor (PF)
0.9
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP20
IK Protection Index
IK05
Strain
165-265VAC
Driver output
30-42V 1050mA
Estimated life (H)
40000
Dimable
No
Isolation class
II
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Energy consumption (kWh/1000h)
28.0
Weight (gr)
1300
Flicker
0.88
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
36
Minimum cri range
93
Maximum cri range
12
Chromaticity x
0.311
Chromaticity y
0.332
Driver
Lifud
Número unidades caja exterior
10.0
Applicable standards
EN 55015:2013;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2013;EN 61000-4-2:2009;EN 61000-4-3:2006;EN 61000-4-4:2004;EN 61000-4-5:2006; EN 61000-4-6:2009; EN 61000-4-8:2010; EN 61000-4-11:2004;1194/2012/EU;874/2012/EU;EN 60598-1:2008;EN 60598-2-2:2012

Characteristics

Product code
HO-PBD-3060-LI-CW
Light temperature
Cold White
Kelvin º
6000
Power (W)
28.0
Luminosity (LM)
2800
Luminous efficacy (LM/W)
100
LED efficacy
110
Type of LEDs
Samsung Led
Number of LEDs
24
Measures (mm)
295x595x35
High
35.0
Long
595.0
Broad
295.0
CRI
80
UGR
◄19
Diffuser
Microprismatic
Power factor (PF)
0.9
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP20
IK Protection Index
IK05
Strain
165-265VAC
Driver output
30-42V 1050mA
Estimated life (H)
40000
Dimable
No
Isolation class
II
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Energy consumption (kWh/1000h)
28.0
Weight (gr)
1300
Flicker
0.88
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
36
Minimum cri range
93
Maximum cri range
12
Chromaticity x
0.311
Chromaticity y
0.332
Driver
Lifud
Número unidades caja exterior
10.0
Applicable standards
EN 55015:2013;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2013;EN 61000-4-2:2009;EN 61000-4-3:2006;EN 61000-4-4:2004;EN 61000-4-5:2006; EN 61000-4-6:2009; EN 61000-4-8:2010; EN 61000-4-11:2004;1194/2012/EU;874/2012/EU;EN 60598-1:2008;EN 60598-2-2:2012

Description

The 30x60 LED Panel with LIFUD flicker free driver with white frame combines a very modern design with excellent efficiency and lighting quality. This Panel is especially suitable for offices and work areas due to its low glare factor.

The light source of the LED panel has a brightness of 2520 lumens, which is equivalent to what a conventional 160W luminaire would emit. In this way, very significant savings are achieved compared to this type of traditional low-consumption luminaires.

Suitable for illuminating offices thanks to its low glare. The glare caused by lighting can negatively influence people, since a comfortable lighting environment is needed to help us in our tasks, a low level of UGR increases the feeling of well-being of workers, which contributes to the level of productivity of indirect way.

Low levels of glare are recommended in all places where long periods of time are spent exposed to artificial light, being very important in offices, educational centers, work areas, etc.

White finish built with aluminum. The panel has an IP20 protection degree (valid for dust and humidity indoors), in addition to being sufficiently robust for the required mechanical demands.

These extra-flat LED screens consume up to 55% less and do not require any type of maintenance, thus avoiding the need to replace primers or ballasts. And having the advantage of being a much lighter and more manageable product.

The LED panel can be used supported on an Armstrong false ceiling, on plasterboard with the help of the fastening clips for LED panels, with which we can recess the panel in the ceiling, or with the suspension kits for LED panels. These kits are made up of four tensioners, one in each corner, allowing us to achieve the desired height or inclination to give the perfect touch to our decoration.

This panel is available in natural white (4200°K) and cool white (6000°K). The indicated color temperature may vary within a tolerance of 7%.
