LED Downlight Spotlight 5W 400Lm 6000ºK Silver Ring 40,000H [PCE-DL5W-P-CW]

LED Downlight Spotlight 5W 400Lm 6000ºK Silver Ring 40,000H [PCE-DL5W-P-CW]

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce / Epistar Led
  • SkuPCE-DL5W-P-CW
  • A 2021
Eprel file
Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening
£5.00
£8.00 £5.00 -37%
Tax included. The Shipping expenses They are calculated on the payment screen.

Available

Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
-37.5%(PCE-DL5W-P-CW_padreImg_pce_dl5w_p_cw_0.jpeg)
Cool White
Available
Free shipping
£5.00
£8.00 £5.00 -37%

Accessories

  • (SB-BS031B_padreImg_sb_bs031b_0.jpeg) (SB-BS031B_padreImg_sb_bs031b_1.jpeg)

    Motion Sensor Recessed 160º ►600W/200W

    Offer
    GreenIce

    Motion Sensor Recessed 160º ►600W/200W

    £4.00
    £6.00 £4.00 -33%
    Offer
  • (SB-BS039_padreImg_sb_bs039_0.jpeg) (SB-BS039_padreImg_sb_bs039_1.jpeg)

    Motion Sensor Surface Mounted 180º IP44 ►1200/300W [SB-BS039]

    Offer
    GreenIce

    Motion Sensor Surface Mounted 180º IP44 ►1200/300W [SB-BS039]

    £8.00
    £14.00 £8.00 -42%
    Offer

Technical file

Product code
PCE-DL5W-P-CW
Luminous efficacy (LM/W)
80
Light temperature
Cold White
Kelvin º
6000
Power (W)
5.0
Luminosity (LM)
400
Measures (mm)
Ø98x33
Roof cut (mm)
Ø64
High
33.0
Diameter
98
Number and type of LEDs
Epistar Led
CRI
80
Power factor (PF)
0.98
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP20
Strain
85-265VAC
Estimated life (H)
40000
Dimable
No
Equivalence (W)
45
Isolation class
II
Work frequency (Hz)
50/ 60
Start time (s)
0.3
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
80000
Diffuser
Milky
Energy consumption (kWh/1000h)
5.0
Weight (gr)
85
Flicker
0.77
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
28
Minimum cri range
94
Maximum cri range
18
Chromaticity x
0.324
Chromaticity y
0.352
Driver output
DC12-24V
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Characteristics

Product code
PCE-DL5W-P-CW
Luminous efficacy (LM/W)
80
Light temperature
Cold White
Kelvin º
6000
Power (W)
5.0
Luminosity (LM)
400
Measures (mm)
Ø98x33
Roof cut (mm)
Ø64
High
33.0
Diameter
98
Number and type of LEDs
Epistar Led
CRI
80
Power factor (PF)
0.98
Construction
Aluminum/PC
Opening Angle (º)
120
Facility
IP20
Strain
85-265VAC
Estimated life (H)
40000
Dimable
No
Equivalence (W)
45
Isolation class
II
Work frequency (Hz)
50/ 60
Start time (s)
0.3
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
80000
Diffuser
Milky
Energy consumption (kWh/1000h)
5.0
Weight (gr)
85
Flicker
0.77
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
28
Minimum cri range
94
Maximum cri range
18
Chromaticity x
0.324
Chromaticity y
0.352
Driver output
DC12-24V
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Description

The Downlight Spotlight is designed for general lighting applications, both commercial and domestic. It provides an intense light with a multitude of possibilities, ideal for replacing traditional halogen lamps, reaching savings of up to 90% and a downlight of low conventional consumption, reaching savings of up to 60% with which high energy efficiency is achieved.

It mounts LEDs -SMD that provide a width of the light beam of 120º. Designed to work at 85-265VAC and a frequency of 50-60Hz.

Equipped with an opal diffuser, it offers a semi-diffuse light ideal for use in both general applications and support lighting for downlights. greater luminosity.Includes high-quality aluminum heat sink and clamps for perfect fixing to the ceiling.

The features of this type of product make it suitable for many spaces, including outside the commercial field, whether in transit areas such as stairs, halls or corridors, and even in work environments such as offices.
