Offer

Strip of 120 LEDs/M 30W 30Lm SMD5630 230VAC IP65 40,000H [WM-SMD5630-G-120-M]

Strip of 120 LEDs/M 30W 30Lm SMD5630 230VAC IP65 40,000H [WM-SMD5630-G-120-M]

See questions and answers

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce
  • SkuWM-SMD5630-G-120-M
Warranty
  • Warranty 3 years
  • 120 º Opening
Documents
£4.00
£9.00 £4.00 -55%
Tax included. The Shipping expenses They are calculated on the payment screen.

Stock available

Warranty
  • Warranty 3 years
  • 120 º Opening
Documents
¿Eres Cliente Profesional?

Hemos publicado una nueva web solo para Profesionales.

ir a Área Profesional
VENTAJAS DE COMPRAR EN GREENICE
  • Precio Mínimo Garantizado
  • Devoluciones Gratis hasta en 60 días
  • Envío Gratis desde 21,95€
  • Hasta 10 años de Garantía
-55.56%(WM-SMD5630-G-120-M_padreImg_wm_smd5630_g_120_m_0.jpeg)
Warm/Cool
Stock available
Free shipping
£4.00
£9.00 £4.00 -55%

Accessories

  • (GR-TAPON-28355630RGB_padreImg_gr_tapon_28355630rgb_0.jpeg) (GR-TAPON-28355630RGB_padreImg_gr_tapon_28355630rgb_1.jpeg)

    End Cap LED Strip SMD2835/5630/RGB 220-230VAC

    GreenIce

    End Cap LED Strip SMD2835/5630/RGB 220-230VAC

    £1.00
    £1.00 £1.00 %
  • (GR-GRAPA2835-5630RGB_padreImg_gr_grapa2835_5630rgb_0.jpeg) (GR-GRAPA2835-5630RGB_padreImg_gr_grapa2835_5630rgb_1.jpeg)

    Staple LED Strip SMD2835/5630/RGB 220-230VAC

    GreenIce

    Staple LED Strip SMD2835/5630/RGB 220-230VAC

    £1.00
    £1.00 £1.00 %
  • (WM-CONT-FC-ES_padreImg_wm_cont_fc_es_0.jpeg) (WM-CONT-FC-ES_padreImg_wm_cont_fc_es_1.jpeg)

    Controller Plug LED Strip 230VAC Cool / Warm

    Offer
    GreenIce

    Controller Plug LED Strip 230VAC Cool / Warm

    £4.00
    £14.00 £4.00 -71%
    Offer

Technical file

Product code
WM-SMD5630-G-120-M
Light temperature
Cold
Power (W)
30.0
Type of LEDs
SMD5630
Measures (mm)
20x50000
Long
50000.0
Broad
20.0
Diffuser
Transparent
Power factor (PF)
0.8
Construction
Epoxy
Opening Angle (º)
120
Facility
IP65
Strain
230-240VAC
Estimated life (H)
40000
Dimable
Yes
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +65
Lighting cycles
80000
Energy consumption (kWh/1000h)
30.0
Weight (gr)
100
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Additional information
Supplied without accessories / See "accessories" tab
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000-3-2:2006; EN 61000-3-3:2008; EPA 3050B:1996; EN 1122B:2001; EPA 3052:1996; EPA 3060A:1996; EPA 7196A:1992; EPA 3540C:1996; EPA 8270D:2007; IEC 62321:2008

Características

Product code
WM-SMD5630-G-120-M
Light temperature
Cold
Power (W)
30.0
Type of LEDs
SMD5630
Measures (mm)
20x50000
Long
50000.0
Broad
20.0
Diffuser
Transparent
Power factor (PF)
0.8
Construction
Epoxy
Opening Angle (º)
120
Facility
IP65
Strain
230-240VAC
Estimated life (H)
40000
Dimable
Yes
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +65
Lighting cycles
80000
Energy consumption (kWh/1000h)
30.0
Weight (gr)
100
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Additional information
Supplied without accessories / See "accessories" tab
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000-3-2:2006; EN 61000-3-3:2008; EPA 3050B:1996; EN 1122B:2001; EPA 3052:1996; EPA 3060A:1996; EPA 7196A:1992; EPA 3540C:1996; EPA 8270D:2007; IEC 62321:2008

Descripción

The Roll of LED Strips is connected directly to the 220V electrical network through a feeder. It is made with high-quality components, allows high heat dissipation and is waterproof thanks to the transparent PVC cover.

Using this roll of strips it is possible to make installations of up to 50 meters per feeder , without risk of voltage drops. It does not require additional transformers, amplifiers or adapters, achieving great savings in materials and labor compared to 12/24V LED strips.

Every meter can be cut, so the 220V LED strips significantly reduce the probability of failures, they use series/parallel circuits, if one zone is damaged (each zone 1 meter) it does not affect the others.< /p>

Due to its flexibility and high luminosity, it is ideal for creating quality lighting in all types of environments, both indoors and outdoors.

Ideal for lighting:< /strong>

  • Facade lighting, ceilings, residences and all kinds of decoration
  • Bridges, monuments, stairs
  • Spectacular lighting, theaters, outdoor areas
  • Emergency lighting, path markings
  • Ambient lighting< li>Lighting for showcases, commercial lighting and shop windows

It is supplied in meters or a roll of 50 meters depending on the quantity. It should not be connected with the rolled strip. p>
