Technical file
Product code
HO-LLS-404800120-CCT
Light temperature
CCT
Power (W)
40.0
Luminosity (LM)
4800
Luminous efficacy (LM/W)
120
LED efficacy
132
Type of LEDs
Osram LED
Number of LEDs
200
Measures (mm)
1200
Long
1200.0
CRI
80
Power factor (PF)
0.98
Construction
Alu/PC
Opening Angle (º)
120
Facility
IP20
IK Protection Index
IK07
Strain
160-265VAC
Estimated life (H)
40000
Isolation class
II
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Temperature range (ºC)
-20+40
Lighting cycles
100000
Energy consumption (kWh/1000h)
40.0
Weight (gr)
800
Flicker
0.78
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
INDEX R9
14
Minimum cri range
5
Maximum cri range
93
Chromaticity x
0.307
Chromaticity y
0.329
Minimum CCT range
3000
Maximum cri range
6000
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001
Description
High-performance LED surface-mounted linear luminaire, designed for direct ceiling or wall installation. Equipped with dimmable CCT (Correlated Color Temperature) technology, it allows the light tone (warm, neutral, or cool) to be selected according to the environment or user preference. It offers homogeneous, flicker-free lighting with excellent energy efficiency, ideal for commercial, light industrial, and residential applications. Technical Specifications
• Luminaire type: LED surface-mounted linear
• Nominal power: 40 W
• Luminous efficacy: 120 lm/W
• Total luminous flux: 4800 lm (±10%)
• Color temperature (CCT): Dimmable – typically 3000 K / 4000 K / 6000 K
• Color rendering index (CRI): ≥80
• Beam angle: 120°
• LED type: High-efficiency SMD (surface-mount)
• Supply voltage: 220–240 V AC, 50/60 Hz
• Power factor (PF): ≥0.9
• THD (Total Harmonic Distortion): ≤15%
• Driver efficiency: ≥85%
• Instant-on: <0.2 s
Construction Features
• Dimensions: 1200 mm (length) × ~75 mm (width) × ~25 mm (height)
• Body material: Extruded aluminum with opal polycarbonate diffuser (high light transmission and anti-glare)
• Body finish: White powder-coated paint (RAL 9003 or equivalent)
• Mounting system: Surface (ceiling or wall) using included metal clips or brackets
• Approximate weight: 0.8–1.0 kg
• Protection rating: IP20 (indoor use)
• Electrical class: Class II (double insulation)
• Thermal management: Passive dissipation through aluminum body
Performance and Durability
• Nominal lifespan (L70/B50): ≥40,000 h
• Number of ON/OFF cycles: >100,000
• Operating temperature: –20°C to +40°C
• Storage temperature: –25°C to +60°C °C
• Lumen maintenance: ≥80% at 70% of lifespan
Additional Features
• Dimmable CCT: Manual or three-level switch selection (3000K / 4000K / 6000K).
• Flicker-free: Yes, via stabilized DC driver.
• Mercury-free and UV/IR radiation-free.
• Instant and silent start.
Recommended Applications
• Offices, retail spaces, classrooms, hallways, hospitals, workshops, homes, parking lots, and common areas.
• Direct replacement for double-tube T8 or T5 fluorescent luminaires (2 x 36 W).
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001
Description
Description
High-performance LED surface-mounted linear luminaire, designed for direct ceiling or wall installation. Equipped with dimmable CCT (Correlated Color Temperature) technology, it allows the light tone (warm, neutral, or cool) to be selected according to the environment or user preference. It offers homogeneous, flicker-free lighting with excellent energy efficiency, ideal for commercial, light industrial, and residential applications. Technical Specifications
• Luminaire type: LED surface-mounted linear
• Nominal power: 40 W
• Luminous efficacy: 120 lm/W
• Total luminous flux: 4800 lm (±10%)
• Color temperature (CCT): Dimmable – typically 3000 K / 4000 K / 6000 K
• Color rendering index (CRI): ≥80
• Beam angle: 120°
• LED type: High-efficiency SMD (surface-mount)
• Supply voltage: 220–240 V AC, 50/60 Hz
• Power factor (PF): ≥0.9
• THD (Total Harmonic Distortion): ≤15%
• Driver efficiency: ≥85%
• Instant-on: <0.2 s
Construction Features
• Dimensions: 1200 mm (length) × ~75 mm (width) × ~25 mm (height)
• Body material: Extruded aluminum with opal polycarbonate diffuser (high light transmission and anti-glare)
• Body finish: White powder-coated paint (RAL 9003 or equivalent)
• Mounting system: Surface (ceiling or wall) using included metal clips or brackets
• Approximate weight: 0.8–1.0 kg
• Protection rating: IP20 (indoor use)
• Electrical class: Class II (double insulation)
• Thermal management: Passive dissipation through aluminum body
Performance and Durability
• Nominal lifespan (L70/B50): ≥40,000 h
• Number of ON/OFF cycles: >100,000
• Operating temperature: –20°C to +40°C
• Storage temperature: –25°C to +60°C °C
• Lumen maintenance: ≥80% at 70% of lifespan
Additional Features
• Dimmable CCT: Manual or three-level switch selection (3000K / 4000K / 6000K).
• Flicker-free: Yes, via stabilized DC driver.
• Mercury-free and UV/IR radiation-free.
• Instant and silent start.
Recommended Applications
• Offices, retail spaces, classrooms, hallways, hospitals, workshops, homes, parking lots, and common areas.
• Direct replacement for double-tube T8 or T5 fluorescent luminaires (2 x 36 W).
