LED Downlight Spotlight 7W 630Lm 6000ºK Rectangular Tilting 40,000H [HO-DLPL-CUAD-7W-CW]

LED Downlight Spotlight 7W 630Lm 6000ºK Rectangular Tilting 40,000H [HO-DLPL-CUAD-7W-CW]

For additional amounts the delivery period is 60 days As of the order date
  • Brand:GreenIce / Epistar Led
  • SkuHO-DLPL-CUAD-7W-CW
  • A 2021
Eprel file
Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 38 º Opening
£3.00
£5.00 £3.00 -40%
Tax included. The Shipping expenses They are calculated on the payment screen.

Stock available

Warranty
  • Warranty 3 years
  • Eye Care Eye Care
  • 38 º Opening
Are you a professional customer?

We have published a new website only for professionals.

Go to Professional Area
Advantages of buying in Greenice
  • Guaranteed minimum price
  • Free returns up to 60 days
  • Free shipping From € 21.95
  • Until 10 years guarantee
-40.0%(HO-DLPL-CUAD-7W-CW_padreImg_ho_dlpl_cuad_7w_cw_0.jpeg)
Cool White
Stock available
Free shipping
£3.00
£5.00 £3.00 -40%

Accessories

  • (GH-90963601_padreImg_gh_90963601_0.jpeg) (GH-90963601_padreImg_gh_90963601_1.jpeg)

    Switch Panasonic Karre 10A 250V/Metal Frame With Claws/Key White

    PANASONIC

    Switch Panasonic Karre 10A 250V/Metal Frame With Claws/Key White

    £5.00
    £5.00 £5.00 %
  • (SB-BS031B_padreImg_sb_bs031b_0.jpeg) (SB-BS031B_padreImg_sb_bs031b_1.jpeg)

    Motion Sensor Recessed 160º ►600W/200W

    Offer
    GreenIce

    Motion Sensor Recessed 160º ►600W/200W

    £4.00
    £9.00 £4.00 -55%
    Offer

Technical file

Product code
HO-DLPL-CUAD-7W-CW
Luminous efficacy (LM/W)
90
Light temperature
Cold white
Kelvin º
6000
Power (W)
7.0
Luminosity (LM)
630
Measures (mm)
90x90x35
Roof cut (mm)
Ø75
High
90.0
Long
90.0
Broad
35.0
Number and type of LEDs
Bridgelux Led
CRI
80
Power factor (PF)
0.9
Construction
Aluminum/PC
Opening Angle (º)
38
Facility
IP20
Strain
170-250VAC
Estimated life (H)
40000
Dimable
No
Equivalence (W)
60
Isolation class
II
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Diffuser
Milky
Energy consumption (kWh/1000h)
7.0
Weight (gr)
300
Flicker
0.87
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
29
Minimum cri range
92
Maximum cri range
16
Chromaticity x
0.31
Chromaticity y
0.336
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Characteristics

Product code
HO-DLPL-CUAD-7W-CW
Luminous efficacy (LM/W)
90
Light temperature
Cold white
Kelvin º
6000
Power (W)
7.0
Luminosity (LM)
630
Measures (mm)
90x90x35
Roof cut (mm)
Ø75
High
90.0
Long
90.0
Broad
35.0
Number and type of LEDs
Bridgelux Led
CRI
80
Power factor (PF)
0.9
Construction
Aluminum/PC
Opening Angle (º)
38
Facility
IP20
Strain
170-250VAC
Estimated life (H)
40000
Dimable
No
Equivalence (W)
60
Isolation class
II
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Diffuser
Milky
Energy consumption (kWh/1000h)
7.0
Weight (gr)
300
Flicker
0.87
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
29
Minimum cri range
92
Maximum cri range
16
Chromaticity x
0.31
Chromaticity y
0.336
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Description

The 90mm Square Tilting LED Downlight with a thickness of (75mm), offers solutions for offices, factories, supermarkets, shops and for residential use. It can be installed directly to the sockets supplied by the electrical network (170-250VAC) with a service frequency of 50 / 60Hz.

It has a high efficiency (85 Lm / W) consuming 7W by means of a COB type LED and managing to provide a luminous flux of 600Lm evenly distributed by an anti-dazzling opal diffuser from which a color rendering index of 80 is obtained. equivalent to a 50W incandescent bulb, its consumption represents a value of 7kWh / 1000h, reducing the amount of energy billed and the emissions of polluting gases into the atmosphere.

Finished in white color built with aluminum and polycarbonate. The Downlight has an IP20 degree of protection (valid for indoor dust and humidity), as well as being sufficiently robust for the required mechanical requirements.

It is made of high quality materials such as aluminum, which ensures the durability of the bulb. Provides uniform lighting without annoying reflections. In addition, it has the CE and RoHS certificates, which are synonymous with quality and safety.

The Downlight has a high color rendering index (CRI 80) and, therefore, ensures distortion-free color reproduction. This factor is key in commercial environments and spaces where products in general are exhibited, such as supermarkets, shops, shopping centers, museums, dealerships, restaurants, etc.

This Downlight is available in natural white (4200 ° K), cool white (6000 ° K) and warm white (3000 ° K). The indicated color temperature may fluctuate corresponding to a tolerance of 7%.
